Bombas Magnéticas de Acionamento para Processo Químico em Aço Inoxidável

no leakage stainless steel magnetic pump
no leakage stainless steel magnetic pump

Bombas Magnéticas de Acionamento para Processo Químico em Aço Inoxidável

The TCH no-leakage stainless steel magnetic pump represents an advanced type of industrial pump. It is characterized by a full-seal design, which effectively eliminates the possibility of leakage. Constructed from stainless steel, it exhibits excellent corrosion resistance. The high-quality magnets incorporated within the pump ensure a reliable magnetic drive, making it well-suited for application in a diverse range of industries.

  • MOQ:

    1

  • Pacote:

    Customzied

  • Cor:

    Customzied

  • Material:

    Steel

  • TEMPERAÇÃO DE TRABALHO:

    -60 to 300 ℃，New material withstands temperatures up to 450°C

  • Pressão de trabalho:

    1.6 to 6.3 MPa
Pergunte agora



Stainless Steel Magnetic Transfer Petrochemical Pump

Product overview

The TCH stainless steel magnetic pump represents an upgrade and innovation built upon the foundation of the TC pump. It has been independently developed and designed as the third generation of a new industrial pump, featuring full sealing, zero leakage, and no pollution.



This pump applies the principle of magnetomechanics, with the medium being enclosed within the static isolation sleeve. Through this design, it is able to achieve non-contact torque transmission. By eliminating the shaft seal device (such as packing seal or mechanical seal) commonly found in traditional centrifugal pumps and replacing the dynamic seal with a static seal, a new type of fully sealed, leak-free magnetic pump has been successfully created.



Stainless Steel Magnetic Transfer Petrochemical Pump

Product advantages

1. The magnet is composed of ferrite magnet, Nd-Fe-B, and samarium cobalt. It exhibits excellent magnetic properties, high temperature resistance, and no demagnetization.

2. The shaft sleeve and sliding bearing are fabricated from highly wear-resistant materials such as silicon carbide, graphite, and tetrafluoro. Additionally, they are equipped with lubrication grooves, which effectively ensure the pump's service life.

3. It is completely leak-free. All sealing points are sealed by closed static seals and driven by a magnetic coupling. There is no need for a nitrogen seal, making it safe, economical, and efficient.



Material List

Part Material Part Material Part Material
① Pump body 304/316/316L ⑥ Seal ring Tetrafluoro ⑪ Pump shaft 304/316/316L/321
② Impeller 304/316/316L ⑦ Sealing sleeve 316L/TA2/HC276 ⑫ Bracket Permenant magnet/HT200
③ Impeller
nut		 304/316/316L ⑧ Plain bearing assembly Carbon fiber/SSIC/Cemented carbide ⑬ Extemal magnet assembly HT250/permenant magnet
④ Pump cover 304/316/316L ⑨ Thrust disc assembly Carbon fiber/SSIC/Cemented carbide ⑭ ELectric machinery Per clients requested
⑤ Thrust disc assembly Carbon fiber/SSIC/Cemented carbide ⑩ Internal magnetic assembly Permenant magnet/304/316/316L/321 ⑮ Plate HT200/A3/Channel steel



Structural diagram

Stainless Steel Magnetic Transfer Petrochemical Pump



Performance Data

Type Rated power Rated flow Rated head Voltage Pump casing material Suction
25-20-125 1.5 2.5 20 380V 304/316/316L 25*20
25-20-160 2.2 2.5 32 380V 304/316/316L 25*20
25-20-200 5.5 2.5 50 380V 304/316/316L 25*20
25-20-250 11 2.5 80 380V 304/316/316L
32-20-125 1.5 3.2 20 380V 304/316/316L 32*20
32-20-160 2.2 3.2 32 380V 304/316/316L 32*20
32-20-200 5.5 3.2 50 380V 304/316/316L 32*20
32-20-250 11 3.2 80 380V 304/316/316L 32*20
40-25-125 2.2 6.3 20 380V 304/316/316L 40*25
40-25-160 3 6.3 32 380V 304/316/316L 40*25
40-25-200 5.5 6.3 50 380V 304/316/316L 40*25
40-25-250 15 6.3 80 380V 304/316/316L 40*25
40-25-315   6.3 125 380V 304/316/316L 40*25
50-32-125 3 12.5 20 380V 304/316/316L 50*32
50-32-160 4 12.5 32 380V 304/316/316L 50*32
50-32-200 7.5 12.5 50 380V 304/316/316L 50*32
50-32-250 15 12.5 80 380V 304/316/316L 50*32
50-32-315   12.5 125 380V 304/316/316L 50*32
65-50-125 4 25 20 380V 304/316/316L 65*50
65-50-160 7.5 25 32 380V 304/316/316L 65*50
65-40-200 15 25 50 380V 304/316/316L 65*40
65-40-250 22 25 80 380V 304/316/316L 65*40
65-40-315 37 25 125 380V 304/316/316L 65*40
65-40-400   25   380V 304/316/316L 65*40
80-65-125 7.5 50 20 380V 304/316/316L 80*65
80-65-160 15 50 32 380V 304/316/316L 80*65
80-50-200 18.5 50 50 380V 304/316/316L 80*50
80-50-250 37 50 80 380V 304/316/316L 80*50
80-50-315 55 50 125 380V 304/316/316L 80*50
80-50-400   50   380V 304/316/316L 80*50
100-80-125 15 100 20 380V 304/316/316L 100*80
100-80-160 22 100 32 380V 304/316/316L 100*80
100-65-200 37 100 50 380V 304/316/316L 100*65
100-65-250 45 100 80 380V 304/316/316L 100*65
100-65-315 75 100 125 380V 304/316/316L 100*65
100-65-400   100   380V 304/316/316L 100*65
125-80-160       380V 304/316/316L 125*80
125-100-200 55 200 50 380V 304/316/316L 125*100
125-100-250 75 200 80 380V 304/316/316L 125*100
125-100-315 22 100 32 380V 304/316/316L 125*100
125-100-400 37 100 50 380V 304/316/316L 125*100
150-125-250 22 200 20 380V 304/316/316L 150*125
150-125-315 45 200 32 380V 304/316/316L 150*125
150-125-400 55 200 50 380V 304/316/316L 150*125
200-150-250 55 400 20 380V 304/316/316L 200*150
200-150-315 75 400 32 380V 304/316/316L 200*150
200-150-400 110 400 50 380V 304/316/316L 200*150



Performance range



Design pressure :1.6~6.3MPa, Flow :0.75~460m³/ h , Lift :5~125m, Power :0.55~110KW.

Applicable temperature :-60~300℃, new materials are adopted , and the temperature resistance can reach 450℃.



Product application



It is extensively utilized for transporting corrosive liquids within the production processes of various industries, such as petroleum, chemical engineering, alkali production, smelting, rare earth extraction, pesticide manufacturing, dye production, pharmaceuticals, papermaking, electroplating, and electrolysis. In particular, it is suitable for handling the transportation of flammable, explosive, volatile, toxic, high-temperature, strong alkali, and organic solvents.
